Connector Terminal Identification - C/K Series
>>
Data Link Connector
Data Link Connector
Fig 1: Data Link - 10-Pin Connector, Black
Courtesy of GENERAL MOTORS CORP.
Courtesy of GENERAL MOTORS CORP.
