Class 2 Data Line Diagnosis

For class 2 data line diagnosis, refer to flowchart. See Fig 1 .

Fig 1: Class 2 Data Line Diagnostic Flowchart

G00138552

Courtesy of GENERAL MOTORS CORP.
