Vehicle Dynamics Control Module (VDM) - Vehicles With: SVT Performance Package: Removal

WARNING: This page is about a different car, the 2020 Ford Mustang. However, it is still accessible from the selected car via links, so may be relevant.

NOTE: Electronic modules are sensitive to static electrical charges. If exposed to these charges, damage may result.

NOTE: Removal steps in this procedure may contain installation details.

Remove the load space floor panel.

Courtesy of FORD MOTOR COMPANY
Remove the load space rear trim panel.

Courtesy of FORD MOTOR COMPANY
Position aside the RH load space trim panel.

Courtesy of FORD MOTOR COMPANY
1. NOTE: Note the position of the components before removal.

  Remove the VDM retainers.

  Torque: 93 lb.in (10.5 Nm)
2. Position the VDM and bracket assembly to gain access to the electrical connector.
Courtesy of FORD MOTOR COMPANY
Disconnect the VDM electrical connector and remove the VDM.

Courtesy of FORD MOTOR COMPANY
