6th Gear Position
| Item | Description |
|---|---|
| 1 | Held components |
| 2 | Driven components |
| 3 | B (4, 6, R) clutch |
| 4 | E (5, 6, 7, 8) clutch |
- In sixth gear, the B (4, 6, R) clutch drives the reaction sun gear at turbine shaft speed.
- The E (5, 6, 7, 8) clutch drives the input ring gear and the reaction sun gear at turbine shaft speed.
- The turbine shaft and the input sun rotate.
- The input carrier and the output ring rotate.
- The Output carrier rotates at 1000 RPM or a 1:1 ratio.
