Automatic Transmission, Transfer Case And Power Transfer Unit - 8-Speed Automatic Transmission - 8F35/8F40 (1 Of 2)
>>
Description And Operation
>>
Transmission Description - System Operation and Component Description
>>
Component Description
>>
Neutral Position
Neutral Position
Courtesy of FORD MOTOR COMPANY
Item
Description
1
Held components
2
Driven components
3
Hydraulic SOWC
With the selector lever in NEUTRAL, the hydraulic SOWC holds the overdrive/reaction planetary carrier stationary.
The turbine shaft drives the center sun gear.
Courtesy of FORD MOTOR COMPANY
