Engine Mount Control Solenoid: Removal

NOTE: Removal steps in this procedure may contain installation details.
  1. Disconnect the electrical, and the vacuum hose connectors. Remove the retainer and the engine mount control solenoid.

    Torque

    : 97 lb.in (11 Nm)

GFD287249Courtesy of FORD MOTOR COMPANY
