Module Controlled Functions - Component Location
Module Controlled Functions - Component Location
Courtesy of FORD MOTOR COMPANY
Item
Description
1
BCM
2
Front door module
3
RFA module
4
Rear door module
Courtesy of FORD MOTOR COMPANY
