Remote Function Actuator (RFA) Module: Installation
WARNING: This page is about a different car, the 2016 Ford Special Service Police Sedan and 2016 Ford Police Interceptor Sedan. However, it is still accessible from the selected car via links, so may be relevant.
- 3.
Program the Intelligent Access (IA) keys (minimum of 2) into the new RFA module. For additional information, refer to Key Programming Using Diagnostic Equipment in Anti-Theft - Passive Anti-Theft System (PATS), With Intelligent Access (IA) .
- 4.
Carry out the parameter reset between the RFA module and the Body Control Module (BCM). For additional information, refer to Passive Anti-Theft System (PATS) Parameter Reset in Anti-Theft - Passive Anti-Theft System (PATS), With Intelligent Access (IA) .
- 5.
Download the RFA module configuration information from the scan tool to the new RFA module by following the scan tool on screen instructions.
- 7.
Carry out the keyless entry keypad code reset. For additional information, refer to Keyless Entry Keypad Code Programming in Handles, Locks, Latches and Entry Systems - With Intelligent Access (IA) .
