Image Processing Module B (IPMB): Removal
WARNING: This page is about a different car, the 2015 Ford C-Max. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
Removal steps in this procedure may contain installation details.
- 1.WARNING: Before beginning any service procedure in this article, refer to Safety Warnings in GENERAL INFORMATION . Failure to follow this instruction may result in serious personal injury.
Refer to: Health and Safety Precautions .
- 2.NOTE: Module configuration is required when a new image processing module B (IPM-B) is being installed.
If a new module is being installed, upload the module configuration information from the IPM-B into the scan tool by following the instructions on the scan tool.
- 3.
Remove the RH loadspace trim panel. Refer to: Loadspace Trim Panel RH .
