OEM Ground Distribution: Grounds: G302

Fig 1: Grounds - Wiring Diagram (G302) (1 Of 2)

G09259556

Courtesy of FORD MOTOR CO.

Fig 2: Grounds - Wiring Diagram (G302) (2 Of 2)

G09259557

Courtesy of FORD MOTOR CO.
