| 1 |
W500303 |
Solenoid body-to-valve body bolt (2 required) |
| 2 |
7A100 |
Main control valve body |
| 3 |
7E195 |
Check balls (3 required) |
| 4 |
7J191 |
Solenoid damper Shift Solenoid A (SSA) |
| 5 |
N605770 |
Solenoid body-to-valve body separator plate bolt (2 required) |
| 6 |
7Z490 |
Solenoid body-to-valve body separator plate |
| 7 |
7K221 |
Circuit filter |
| 8 |
7G391 |
Solenoid body |
| 9 |
W505513 |
Transmission internal wiring harness frame screw (5 required) |
| 10 |
7G276 |
Transmission internal wiring harness frame |
| 11 |
7H111 |
Solenoid retaining pin (14 required) |
| 12 |
7C389 |
Manual valve |
| 13 |
7G473 |
Solenoid pressure regulator valve assembly |
| 14 |
7G179 |
Clutch bypass valve |
| 15 |
7G307 |
Torque Converter Clutch (TCC) regulator valve |
| 16 |
7B200 |
Control pressure regulator |
| 17 |
7D102 |
Direct (3, 5, R) clutch regulator valve |
| 18 |
7D102 |
Intermediate (2, 6) clutch regulator valve |
| 19 |
7D102 |
Forward (1, 2, 3, 4) clutch regulator valve |
| 20 |
7J187 |
Forward (1, 2, 3, 4) clutch latch valve |
| 21 |
7D102 |
Low reverse/overdrive (4, 5, 6) clutch regulator valve |
| 22 |
7J187 |
Direct (3, 5, R) clutch latch valve |
| 23 |
7J187 |
Intermediate (2, 6) clutch latch valve |
| 24 |
7J187 |
Low reverse/overdrive (4, 5, 6) clutch latch valve |
| 25 |
7G383 |
Line Pressure Control (LPC) solenoid |
| 26 |
7G136 |
Shift Solenoid C (SSC) |
| 27 |
7G136 |
Torque Converter Clutch (TCC) solenoid |
| 28 |
7G484 |
Shift Solenoid E (SSE) ON/OFF solenoid |
| 29 |
7G136 |
Shift Solenoid A (SSA) |
| 30 |
7G383 |
Shift Solenoid B (SSB) |
| 31 |
7G383 |
Shift Solenoid D (SSD) |
