OEM Ground Distribution: Grounds: G206

Fig 1: Grounds - Wiring Diagram - G206 (1 Of 2)

G09222565

Courtesy of FORD MOTOR CO.

Fig 2: Grounds - Wiring Diagram - G206 (2 Of 2)

G09222566

Courtesy of FORD MOTOR CO.
