Exploded View
WARNING: This page is about a different car, the 2014 Ford Explorer. However, it is still accessible from the selected car via links, so may be relevant.
| Item | Service Part Number | Description | Tool Number | Material Name | Notes |
|---|---|---|---|---|---|
| 1 | - | Transmission shift cable adjustment lock (part of 7E395) | - | - | - |
| 2 | 7H181 | Transmission shift cable rotating slide snap | - | - | - |
| 3 | W711892 | Transmission manual control lever nut | - | - | 18 Nm (159 lb-in) |
| 4 | 7A256 | Transmission manual control lever | - | - | - |
| 5 | 11N087 | Starter motor solenoid battery cable terminal cover | - | - | - |
| 6 | W706414 | Starter motor solenoid battery cable nut | - | - | 12 Nm (106 lb-in) |
| 7 | - | Starter motor solenoid battery cable terminal (part of 14300) | - | - | - |
| 8 | W705790 | Starter motor solenoid wire nut | - | - | 5 Nm (44 lb-in) |
| 9 | - | Starter motor solenoid wire terminal (part of 14300) | - | - | - |
| 10 | - | Wiring harness retainer (part of 14300) | - | - | - |
| 11 | W715721 | Starter motor stud bolt (2 required) | - | - | 48 Nm (35 lb-ft) |
| 12 | 11002 | Starter motor | - | - | - |
