Steering Column Multifunction Switch LH: Removal

WARNING: This page is about a different car, the 2017 Ford Edge. However, it is still accessible from the selected car via links, so may be relevant.
NOTE: Removal steps in this procedure may contain installation details.

  1. 1.

    Remove the steering column shrouds. Refer to: Steering Column Shrouds .

  1. 2.

    If equipped, remove the steering column control switch. Refer to: Steering Column Control Switch .

  1. 3.

    NOTE: Make sure the component terminals are not bent or damaged.

    Remove the screw(s) and the steering column multifunction switch.

GFD19042Courtesy of FORD MOTOR COMPANY
