Intake Manifold (View 5 of 5): Notes
WARNING: This page is about a different variant/trim than selected.
Courtesy of FORD MOTOR CO.
| Item |
Part Number |
Description |
| 1 |
W707083 |
Intake manifold bolt (2 required) |
| 2 |
W503279 |
Intake manifold bolt (10 required) |
| 3 |
9424 |
Intake manifold |
| 4 |
9439 |
Coolant by-pass tube gasket |
| 5 |
9439 |
Coolant crossover gasket (2 required) |
| 6 |
9439 |
Intake manifold gasket (6 required) |
