Selector Lever Knob: Installation

  1. Route the TCS wiring through the selector knob shroud and selector lever.
    1. Position the TCS wire towards the back right corner of the selector knob shroud.
    2. Route the TCS wire through the selector lever opening.
      Fig 1: Identifying Selector Knob Shroud And Selector Lever
      G07488546Courtesy of FORD MOTOR CO.
    2. NOTE: Keep the TCS wire taught while installing the selector lever knob.
    Fig 2: Identifying Selector Lever Knob
    G07488547Courtesy of FORD MOTOR CO.
  2. Install the selector lever knob.
    3. NOTE: Tightening the transmission selector lever knob screws over 2 Nm (18 lb-in) may damage the selector lever assembly.
  3. Align the transmission selector lever knob base screw hole with the selector shaft and install the selector lever knob screws.
    • Tighten to 2 Nm (18 lb-in).
      Fig 3: Locating Selector Lever Knob Screw
      G07488545Courtesy of FORD MOTOR CO.
  4. Slide the selector lever knob shroud up and snap into position.
    Fig 4: Sliding Selector Lever Knob Shroud Up
    G07488549Courtesy of FORD MOTOR CO.
    5. NOTE: Make sure the TCS wire is pulled taught prior to connecting the TCS.
    Fig 5: Locating Transmission Control Switch Electrical Connector
    G07488543Courtesy of FORD MOTOR CO.
  5. Connect the Transmission Control Switch (TCS) electrical connector.
  6. Install the selector lever. For additional information, refer to SELECTOR LEVER .
