Receiver Drier: Removal
WARNING: This page is about a different variant/trim than selected.
NOTE:
Removal steps in this procedure may contain installation details.
-
WARNING: Before beginning any service procedure, refer to Safety Warnings in GENERAL INFORMATION -- FOCUS ELECTRIC . Failure to follow this instruction may result in serious personal injury.
Refer to: CLIMATE CONTROL SYSTEM HEALTH AND SAFETY PRECAUTIONS .
- Refer to: AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING .
- Refer to: JACKING AND LIFTING - OVERVIEW .
- Both sides.
Torque: 25 Nm
- Torque:
25 Nm
