Exploded View
WARNING: This page is about a different variant/trim than selected.
Courtesy of FORD MOTOR CO.
| Item |
Service Part Number |
Description |
Torque |
Material Name |
Notes |
| 1 |
W714682 |
Engine mount-to-engine nut (4 required) |
63 Nm (46 lb-ft) |
- |
- |
| 2 |
W712507 |
Engine mount-to-frame bolt (3 required) |
90 Nm (66 lb-ft) |
- |
- |
| 3 |
6038 |
Engine mount |
- |
- |
- |
