Exploded View

WARNING: This page is about a different car, the 2013 Ford Explorer. However, it is still accessible from the selected car via links, so may be relevant.
G07420773
Item Service Part Number Description Tool Number Material Name Notes
1 - Pedal adjust switch screw - - 3 Nm (27 lb-in)
2 9G604 Pedal adjust switch - - -
