Illustration 7

WARNING: This page is about a different car, the 2012 Ford Fiesta. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Example Of Exhaust Manifold Bolts Removal Order
G07420537Courtesy of FORD MOTOR CO.

Standard tool symbols direct the use of standard tools to perform a service action, such as the cutting of carpet shown in Illustration 8 . Tool symbols may include dimensional values (for example, a drill with a specified diameter).
