Illustration 6

WARNING: This page is about a different car, the 2012 Ford Fiesta. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Example Of Gearshift Lever Or Selector Lever Position Symbols
G07420536Courtesy of FORD MOTOR CO.

Callouts or arrows may be used to identify components for supporting special information, such as a required sequence or to indicate a number of identical components. Illustration 7 shows a removal order in the top graphic and the bottom graphic indicates 12 identical bolts.
