Illustration 5

WARNING: This page is about a different car, the 2012 Ford Fiesta. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Example Of Location Showing Symbols
G07420535Courtesy of FORD MOTOR CO.

Illustration 6 shows how gearshift lever or selector lever position symbols may be used to indicate the gearshift lever or selector lever position required. The required Essential Special Service Tool to align the shift mechanism is shown in pale blue and identified by ESST number.
