Headlamp Assembly: Notes
WARNING: This page is about a different car, the 2014 Lincoln MKX and 2014 Ford Edge. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
For information on Ford Color Coded Illustrations refer to COLOR-CODING - FORD
.
NOTE:
Edge shown in illustration, MKX similar.
| Item | Part Number | Description |
|---|---|---|
| 1 | W505425 | Front headlamp assembly bolts (2 required) |
| 2 | 13008 | Headlamp assembly (RH/LH) |
| 3 | W505425 | Side headlamp assembly bolt |
| 4 | W505425 | Upper headlamp assembly bolt |
| 5 | - | Headlamp electrical connectors (part of 14A464) |
