Seat Control Switch With Power Liftgate

Fig 1: Identifying Power Liftgate Strut Cover, Quarter Trim Panel And Electrical Connector
G07403199Courtesy of FORD MOTOR CO.
ITEM DESCRIPTION CHART

Item Part Number Description
1 - Electrical connector (part of 14A005)
2 14C715 Seat control switch
3 - Power liftgate strut cover
