Turbine Shaft Speed (TSS) Sensor: Notes

Fig 1: Turbine Shaft Speed (TSS) Sensor Replacement Components With Torque Specifications
G06260021Courtesy of FORD MOTOR CO.
ITEM DESCRIPTION

Item Part Number Description
1 7J291 Bolt - solenoid body
2 7Z369 Solenoid body
3 7J291 Bolts - valve body
4 7E332 Manual valve detent spring
5 7A100 Valve body
6 7J356 Turbine Shaft Speed (TSS) sensor bolt
7 7M101 TSS sensor
