Pinch Strip Switch: Notes
WARNING: This page is about a different car, the 2009 Ford Flex. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
Left side shown, right side similar.
Courtesy of FORD MOTOR CO. PCM DTC CHART
| Item |
Part Number |
Description |
| 1 |
- |
Liftgate |
| 2 |
|
Pinch strip electrical connector |
| 3 |
42430B |
Pinch strip switch |
| 4 |
- |
Pushpin retainers (3 required) (part of 42430B) |
| 5 |
- |
Scrivet (part of 42430B) |
