Home >> Ford >> 2008 >> Expedition RWD >> Repair and Diagnosis >> Restraints >> Restraints Control Systems >> Safety Belt System >> Removal And Installation >> Safety Belt Buckle - Front, Center >> Notes

Safety Belt Buckle - Front, Center: Notes

Fig 1: Exploded View Of Front Center Safety Belt Buckle With Torque Specification
GF0021814Courtesy of FORD MOTOR CO.
Item Part Number Description
1 611B60 Front center safety belt buckle
2 N811712 Front center safety belt buckle bolt
