Front Impact Severity Sensor: Notes

Fig 1: Front Impact Severity Sensor Replacement Components With Torque Specifications
GF0019493Courtesy of FORD MOTOR CO.
Item Part Number Description
1 - Front impact severity sensor electrical connector (part of 14290)
2 W707722 Front impact severity sensor bolts
3 14B006 Front impact severity sensor
4 W705436 Pin-type retainers
5 8150 Grille assembly
