Special Tool(s)
WARNING: This page is about a different car, the 2005 Mercury Sable and 2005 Ford Taurus. However, it is still accessible from the selected car via links, so may be relevant.
SPECIAL TOOL SPECIFICATIONS
| Worldwide Diagnostic System (WDS) Vehicle Communication Module (VCM) with appropriate adapters, or equivalent diagnostic tool |
|
| Rotunda 73 III Automotive Meter 105-R0057 or equivalent | |
| R134a Manifold Gauge Set 176-R032A or equivalent | |
| Vacuum Pump Kit 416-D002 (D95L-7559-A) or equivalent | |
| Connector, Refrigerant Pressure Line 412-093 (T94P-19623-E) | |
| Set, A/C Fittings 412-DS028 (014-00333, D93L-19703-B) or equivalent | |
| Refrigerant Leak Detector 216-00001 or equivalent | |
| Pressure Test Kit 014-R1072 or equivalent | |
| Breakout Box, EEC V Control System 418-049 (014-00950, T94L-50-EEC-V) | |
| Starter, Alternator, Battery, Regulator Electrical Tester (S.A.B.R.E.) 010-00736 or equivalent |
