Air Inlet Duct: Notes

Fig 1: Identifying Air Inlet Duct
GF0040375Courtesy of FORD MOTOR CO.
Item Part Number Description
1 W703056-S305 Clip (2 required)
2 - Screw (2 required)
3 W703056-S305 Clip (2 required)
4 - Air inlet duct
