| 1 |
N805024 |
Battery ground cable nut |
| 2 |
- |
Battery ground cable terminal (part of 14B060) |
| 3 |
N805320 |
Starter solenoid wire nut |
| 4 |
- |
Starter solenoid wire terminal (part of 14B060) |
| 5 |
W706414 |
Starter solenoid positive cable nut |
| 6 |
- |
Starter solenoid positive cable terminal (part of 14B060) |
| 7 |
- |
Battery ground cable-to-frame bolt (part of 14B060) |
| 8 |
- |
Battery ground cable frame terminal (part of 14B060) |
| 9 |
N621906 |
Battery cable harness bracket nuts (2 required) |
| 10 |
W520101 |
Generator harness terminal/central junction box (CJB) cable nut |
| 11 |
- |
CJB cable terminal (part of 14300) |
| 12 |
- |
Generator harness terminal (part of 14305) |
| 13 |
N806925 |
Battery ground cable-to-cowl panel bolt |
| 14 |
- |
Battery ground cable-to-body terminal (part of 14B060) |
| 15 |
- |
Battery cable harness in-line electrical connector (part of 14B060) |
| 16 |
14B060 |
Battery cable harness assembly |
