Seat Cushion - Rear: Notes

Fig 1: Exploded View Of Rear Seat Cushion With Torque Specifications
GF0023749Courtesy of FORD MOTOR CO.
Item Part Number Description
1 56906-S Rear seat cover
2 7860081 Rear seat base cushion
3 56906-S Rear seat base
4 W707122-S Rear seat base bracket bolts (2 required)
5 C2FU60710-B Rear seat base bracket
