Passenger Air Bag Module - MKX: Notes

Fig 1: Exploded View Of Passenger Air Bag Module With Torque Specifications - MKX

Courtesy of FORD MOTOR CO.

Item	Part Number	Description
1	04338	RH instrument panel (I/P) finish panel
2	W707628	LH duct assembly bracket screw
3	19B680	LH duct assembly
4	19B680	RH duct assembly
5	W707628	LH duct assembly screw
6	W707628	RH duct assembly screw
7	W701014	Passenger air bag module nuts (3 required)
8	-	Passenger air bag module electrical connectors (2 required) (part of 14401)
9	044A74	Passenger air bag module
10	-	Passenger air bag module support bracket
11	W505422	Inboard passenger air bag module-to-bracket bolt
12	W505422	Outboard passenger air bag module-to-bracket bolt
13	W503922	Passenger air bag module bracket-to-cross vehicle beam bolts (2 required)
