Home >> Ford >> 2005 >> Mustang GT, 2D Convertible, Automatic >> Repair and Diagnosis >> Brakes >> Traction Control >> Anti-Lock Brake System >> Removal And Installation >> Wheel Speed Sensor - Rear >> Notes

Wheel Speed Sensor - Rear: Notes

Fig 1: Identifying Rear Wheel Speed Sensor

G03983487

Courtesy of FORD MOTOR CO.
