Toe Adjustment

Start the engine (6007) and center the steering wheel (3600).

Fig 1: Centering Steering Wheel
Courtesy of FORD MOTOR CO.
Turn the engine off, and hold the steering wheel in the "straight forward" position by attaching a rigid link from the steering wheel to the brake pedal.
Check the toe settings; follow the manufacturer's instructions.

NOTE: Do not allow the steering gear bellows to twist when the front wheel spindle tie-rod (3280) is rotated.

Fig 2: Removing Clamps

Courtesy of FORD MOTOR CO.

Remove the clamps.
Loosen the nuts.
- Clean and lubricate the nut(s) and front wheel spindle tie-rod threads.
Fig 3: Loosening Nuts
Courtesy of FORD MOTOR CO.
Rotate the front wheel spindle tie-rods.

Fig 4: Rotating Front Wheel Spindle Tie-Rods
Courtesy of FORD MOTOR CO.
Tighten the nuts.

Fig 5: Tightening Nuts
Courtesy of FORD MOTOR CO.
Install the clamps.

Fig 6: Installing Clamps
Courtesy of FORD MOTOR CO.
Recheck the toe settings; follow the manufacturer's instructions.
