Piston - Diameter

  1. Measure the piston dome and skirt diameter 90 degrees from the piston pin at the points indicated. For additional information, refer to SPECIFICATIONS .
    • If it is out of specification, install new components as necessary. Refer to ENGINE - 4.0L SOHC for the procedure.
      Fig 1: Measuring Piston Dome And Skirt Diameter 90 Degrees From Piston Pin
      G03233364Courtesy of FORD MOTOR CO.
