Disassembly And Assembly Of Subassemblies: Synchronizers: Assembly

  1. Match the marked parts for assembly. Assemble the synchronizer.
    1. Install the sleeve.
    2. Install the insert keys.
    3. Install the retaining spring.
    4. Flip the synchronizer over and install the opposite retaining spring.
    Fig 1: Assembling Synchronizer
    G01300684Courtesy of FORD MOTOR CO.
