Input Shaft and Bearing: Disassembly

  1. Using the special tool and a press, remove the input bearing (7025).
    Fig 1: Removing Input Bearing
    G03402539Courtesy of FORD MOTOR CO.
  2. Remove the bearing race and the end play selective shims.
    Fig 2: Removing Bearing Race And End Play Selective Shims
    G03402540Courtesy of FORD MOTOR CO.
  3. Remove the input shaft seal (7052).
