Inner Tie Rod: Installation
WARNING: This page is about a different car, the 2004 Ford Ranger. However, it is still accessible from the selected car via links, so may be relevant.
- Lubricate the front wheel spindle tie-rod inner groove with steering gear grease where the front suspension steering ball stud boot seal is clamped.
- Check that the front suspension steering ball stud boot seal is positioned correctly over the steering gear housing bead at the large inside diameter (ID) and is in the front wheel spindle tie -rod groove at the small ID.
- Check that the front suspension steering ball stud boot seal is not twisted and the breather tube is securely inserted into the breather nipple at both front suspension steering ball stud boot seals.
- To install, reverse the removal procedure.
- Check the wheel alignment. Adjust as necessary. For additional information, refer to SUSPENSION SYSTEM-GENERAL INFORMATION .
