Section 26 (Steering Column Switches): Description
WARNING: This page is about a different car, the 2002 Lincoln Navigator, 2002 Ford Expedition, 2001 Lincoln Navigator, and 2001 Ford Expedition. However, it is still accessible from the selected car via links, so may be relevant.
WARNING:
Vehicles are equipped with air bag supplemental restraint system. Before attempting ANY repairs involving steering column, instrument panel or related components, see AIR BAG SAFETY PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM in appropriate AIR BAG RESTRAINT SYSTEMS article in RESTRAINTS.
Multifunction switch, located on steering column, includes flash-to-pass and front windshield wiper/washer switches. Ignition switch and lock cylinder are also mounted on steering column. Horn switch is integrated into air bag module. Horn system includes clockspring, horn, central security module, horn switch and steering wheel control harness. Steering wheel also contains cruise control switches. For diagnostic information on cruise control switches, see appropriate CRUISE CONTROL SYSTEMS article. Steering column switch circuits are protected by battery junction box maxi-fuses No. 102 (50-amp), No. 103 (50-amp), No. 111 (40-amp) and No. 113 (40-amp). See Fig 1.
