New Identification Labels For Paint Code Changes (92-5-2)

WARNING: This page is about the Taurus GL, 4D Sedan, 3.0 1, which is a different variant/trim than selected.

Publication date: 1992-12-26
Reference number: 92-5-2

NEW IDENTIFICATION LABELS FOR PAINT CODE CHANGES

TECHNICAL SERVICE BULLETIN

Reference Number(s): 92-5-2

PAINT - NEW IDENTIFICATION LABELS FOR PAINT CODE CHANGES

Model(s): Ford: 1992-on Crown Victoria, Escort,

Mustang, Taurus, Tempo,

Thunderbird

Lincoln-Mercury: 1992-on Continental, Cougar,

Grand Marquis, Mark VII,

Sable, Topaz, Town Car,

Tracer

Light Truck: 1992-on All Light Truck Lines

Medium/Heavy Truck: 1992-on All Medium/Heavy Truck Lines Bulletin No.: 92-5-2 Date: February 26, 1992

ISSUE

A new special paint identification label has been designed to identify R.P.O. paint code changes on the subject vehicles not reflected on the certification label. Examples of paint changes are...

Running color changes during the model year, where a monocoat paint was changed to basecoat/clearcoat.
Future model color is in a pre-production color trial.

ACTION

If paint service is required, refer to this special paint identification label affixed near the certification label to find the Ford "M" number and the two digit sales code. See Fig 1 . This label is for short run use only until certification labels can be changed. This process is automated and takes approximately two (2) weeks time. Aftermarket paint suppliers can track colors by either of the provided codes.

WARRANTY INFORMATION

WARRANTY STATUS: Information Only.

OASIS CODES: 106000

Fig 1: Special Paint Identification Label
