MOTORCRAFT Electro-Mechanical Regulator: Description
Alternator Regulator is composed of two control units, a field relay and a voltage limiter, mounted as an assembly. The field relay serves to connect charging system voltage to field circuit while engine is running. Voltage limiter is double contact unit which controls amount of current supplied to alternator rotating field. The regulator is factory calibrated, has no adjustment and must be replaced if defective.
