Sensor & Switches: Notes
- For removal and installation procedures, see Fig 1
. For installation procedures, follow the numbered steps in the illustration in reverse order.
- Numbered steps in illustration refer to service points to observe while removing and installing headlining. Arrows pointing AWAY from each other refer to service points to be observed while performing that step of the removal procedure. Arrows pointing TOWARD each other refer to service points to be observed while performing that step of the installation procedure.
- More detail on specific step(s) is covered, as necessary, under POINTS OF REMOVAL & INSTALLATION
.
Courtesy of CHRYSLER CORP.
