Sensor, Oil Temperature: Installation

GC0173767Courtesy of CHRYSLER GROUP, LLC
  1. Install the oil temperature sensor (1) and tighten to the proper specification. Refer to TORQUE SPECIFICATIONS .
    GC0173564Courtesy of CHRYSLER GROUP, LLC
  2. Connect the oil temperature sensor wire harness connector (2).
  3. Install the cowl extension. Refer to SILENCER, COWL EXTENSION, INSTALLATION .
  4. Connect the negative battery cable.
