Module, Drivetrain Control (DTCM): Installation

GC0095226Courtesy of CHRYSLER GROUP, LLC
  1. Slide the Drive Train Control Module (3) on the mounting stud (6) and over mounting stud (5).
  2. Install the mounting nuts (2 and 4). Tighten the nuts to 16 N.m (12 ft. lbs.).
    GC0170340Courtesy of CHRYSLER GROUP, LLC
  3. Install the cowl side trim panel (1).
