Non SRT

Fig 1: Front Suspension

Courtesy of CHRYSLER GROUP, LLC

Each side of the front suspension includes the following components:

• Hub And Bearing
• Knuckle (3)
• Lower Control Arm (5)
• Shock Assembly (1)
• Stabilizer Bar and Link (7)
• Tension Strut (4)
• Upper Control Arm (2)
