Section 2 (2.4L Engine (Service Information)): Installation: Base

WARNING: This page is about a different variant/trim than selected.
Fig 1: LIFT CHAIN
GC0102964Courtesy of CHRYSLER LLC
  1. Position engine over engine compartment and slowly lower into place.
  2. Align engine and transaxle.
  3. Install upper bellhousing bolts and tighten.
    Fig 2: RIGHT ENGINE MOUNT
    GC0102965Courtesy of CHRYSLER LLC
  4. Install mounting bolts (3) at the right mount bolts and tighten bolts to 118 N.m (87 ft. lbs.).
    Fig 3: MODULAR CLUTCH TO FLEX PLATE BOLT
    GC0102966Courtesy of CHRYSLER LLC
  5. Install clutch to flex plate bolts (1).
  6. Install lower bell housing bolts (2) and tighten.
    Fig 4: INSPECTION COVER
    GC0102967Courtesy of CHRYSLER LLC
  7. Install inspection cover (1).
    Fig 5: Crankshaft Position Sensor
    GC0102968Courtesy of CHRYSLER LLC
  8. Connect crankshaft position sensor (2). Connect crankshaft position sensor electrical connector.
  9. On AWD vehicles, install maniverter. See Engine/Manifolds/MANIFOLD, Exhaust - Installation .
    Fig 6: GROUND STRAP
    GC0102969Courtesy of CHRYSLER LLC
  10. Install Ground strap (1).
  11. Raise vehicle.
    Fig 7: EXHAUST TO MANIVERTER BOLTS
    GC0138487Courtesy of CHRYSLER LLC
  12. On AWD vehicles, install maniverter to exhaust pipe bolts (1) and tighten bolts.
    Fig 8: Identifying Exhaust Pipe & Strap
    GC0102970Courtesy of CHRYSLER LLC
  13. On FWD vehicles, remove strap (2) from exhaust pipe (1).
    Fig 9: CAT AT EXHAUST MANIFOLD
    GC0102918Courtesy of CHRYSLER LLC
  14. On FWD vehicles, install new manifold to catalytic converter gasket (1) and install catalytic converter to exhaust manifold and tighten.
  15. Connect oxygen sensor electrical connector (3).
  16. Install generator.
    Fig 10: A/C COMPRESSOR
    GC0102971Courtesy of CHRYSLER LLC
  17. Install A/C compressor (1).
    Fig 11: Removing & Installing Damper Bolt & Damper
    GC0102972Courtesy of CHRYSLER LLC
  18. Install crankshaft damper.
  19. Apply clean engine oil crankshaft damper bolt threads and between bolt head and washer. Tighten bolt to 210 N.m (155 ft. lbs.).
  20. Install right splash shield.
  21. Install right tire.
    Fig 12: OIL COOLER
    GC0102973Courtesy of CHRYSLER LLC
  22. Install oil cooler if equipped (2). See Engine/Lubrication/COOLER, Oil - Installation .
  23. Connect coolant hoses to oil cooler (2), if equipped.
  24. Install new oil filter (3).
  25. Lower vehicle.
  26. Install upper idler pulley.
    Fig 13: POWER STEERING LINE SUPPORT
    GC0102974Courtesy of CHRYSLER LLC
  27. Install power steering pump.
  28. Install power steering line support bracket at engine mount (1).
    Fig 14: POWER STEERING HOSE SUPPORT-FWD
    GC0102975Courtesy of CHRYSLER LLC
  29. On FWD vehicles, install power steering hose support (2) at exhaust manifold.
  30. Install accessory drive belt.
    Fig 15: Removing/Installing Intake Bolts In Sequence
    GC0082457Courtesy of CHRYSLER LLC
  31. Connect electrical connectors at block ground, starter, A/C compressor, knock sensor, Oil pressure sensor, generator, Coolant temperature sensor at block, and block heater.
  32. Install intake manifold. See Engine/Manifolds/MANIFOLD, Intake - Installation .
    Fig 16: THROTTLE BODY SUPPORT
    GC0102976Courtesy of CHRYSLER LLC
  33. Install throttle body support bracket (1).
  34. Install engine oil dip stick.
  35. Install vacuum lines at throttle body and intake manifold.
  36. Connect manifold flow control valve and electronic throttle control electrical connectors and fasten harness to intake.
    Fig 17: COIL CONNECTOR
    GC0084062Courtesy of CHRYSLER LLC
  37. Install intake air tube on throttle body.
  38. Install PCV hose (5) to valve cover.
  39. Connect fuel line (3) to fuel rail.
  40. Connect coils (1), injectors (4), oil temperature sensor, cam position sensors.
    Fig 18: RADIATOR HOSE SUPPORT
    GC0102977Courtesy of CHRYSLER LLC
  41. Install upper radiator support bracket (1).
    Fig 19: COOLANT ADAPTER
    GC0102978Courtesy of CHRYSLER LLC
  42. Connect engine coolant temperature sensor (1), and capacitor (2).
  43. Install coolant hoses at coolant adapter (3).
  44. Connect purge hose (4).
    Fig 20: COOLANT RESERVOIR
    GC0102979Courtesy of CHRYSLER LLC
  45. Install coolant reservoir (3) and connect hose.
    Fig 21: BATTERY TRAY
    GC0102980Courtesy of CHRYSLER LLC
  46. Install battery tray (1).
    Fig 22: BATTERY
    GC0102981Courtesy of CHRYSLER LLC
  47. Install hood.
  48. Install battery (3).
  49. Connect battery cables.
    Fig 23: AIR CLEANER HOUSING
    GC0102982Courtesy of CHRYSLER LLC
  50. Install air cleaner housing (1) and connect inlet air hose (5).
    Fig 24: AIR CLEANER INLET
    GC0102983Courtesy of CHRYSLER LLC
  51. Install fresh air inlet (2) and tighten retainers (5).
  52. Fill with coolant. Refer to Cooling - Standard Procedure .
  53. Fill with oil.
    Fig 25: ENGINE COVER-2.4L
    GC0102984Courtesy of CHRYSLER LLC
  54. Start engine and check for leaks.
  55. Install engine cover (1).
