Rocker Arms: Removal

NOTE: Before replacing parts, inspect all related valvetrain components for damage to prevent engine misfire.
  1. Remove cylinder head cover(s) (Refer to ENGINE/CYLINDER HEAD/CYLINDER HEAD COVER(S) - REMOVAL) .
  2. Remove two rocker pedestal bolts per each cylinder. See Figure.
  3. Remove rocker arm assemblies as a pair. See Figure.
  4. If rocker arm assemblies are disassembled for cleaning or replacement, reassemble rocker arms in their original position.
