Reading Lamp Connector Connector End View
Reading Lamp Connector Connector End View
READING LAMP CONNECTOR
Courtesy of DAIMLERCHRYSLER CORP.
CAV
CIRCUIT
FUNCTION
1
16BR
GROUND
2
16RD/YL
MAP/READING LAMP SWITCH OUTPUT
