Passenger Power Window Motor Connector End View

POWER WINDOW MOTOR-PASSENGER

GCVA580222Courtesy of DAIMLERCHRYSLER CORP.
CAV CIRCUIT FUNCTION
1 16BL PASSENGER WINDOW DRIVER (DOWN)
2 16BK PASSENGER WINDOW DRIVER (UP)
